Date Published: 07 / 05 / 2014Written in UK English V1Original InstructionsSTEALTH255ENFRDENLITJP255

(2.5)4) General Power Tool Safety Warnings [Power tool use and care]. a) Do not force the power tool. Use the correct power tool for your application

3.5 MITRE SAW SPECIFIC SAFETYThe following specic safety instructions for Mitre Saws are based on the requirements of EN61029-2-9:2009.BLADE SAFET

3.7SAFE OPERATIONAlways ensure that you have selected the correct saw blade for the material being cut. Do not use this mitre saw to cut materials o

• To reduce the risk of back injury, hold the tool close to your body when lifting. Bending your knees so you can lift with your legs, not your back.

OVERALL VIEW OF MITRE SAW 1. ON/OFF TRIGGER SWITCH 2. LOCK-OFF BUTTON3. CUTTING HANDLE 4. DUST BAG (Optional Accessory) 5. ROTARY TABLE 6. TABLE TOP

7.1 ASSEMBLY AND PREPARATIONWARNING: Always disconnect the saw from the power source before making any adjustments.Note: It is recommended that all

16www.evolutionpowertools.comThis arm will provide extra stability to prevent the machine from toppling in the event of sudden release of the Cutting

17www.evolutionpowertools.comENFRDENLITJPLASER ADJUSTMENT FOR EUROPEAN PLUG MODELSWARNING: At no time during this procedure should the motor be starte

18www.evolutionpowertools.comLASER ADJUSTMENT FOR NORTH AMERICAN PLUG MODELSWARNING: At no time during this procedure should the motor be started.The

19www.evolutionpowertools.comENFRDENLITJPNote: The above adjustments & alignments should be checked on a regular basis to ensure laser accuracy.No

TABLE OF CONTENTS*English Page 02Deutsch Seite 40Français Page 82Italiano Pagina 126日本語 ページ 168Nederlands Pagina 204MACHINE SPECIFICATION 04Introducti

20www.evolutionpowertools.comTo use the laser guide for an unknown angle:• Mark the position of the cut to be made on the workpiece using a pencil et

21www.evolutionpowertools.comENFRDENLITJP• Whencuttingiscompletere-adjustthedepthstopsothattheCutting Head can be locked in the down posit

(8.3)BODY AND HAND POSITIONING (Fig. 11)• Never place your hands within the ‘no hands zone’ (at least 150mm away from the blade). Keep hands away fro

23www.evolutionpowertools.comENFRDENLITJPBEVEL ANGLES (00 AND 450)00 Bevel Stop Adjustment• Ensure that the Cutting Head is in the locked down positi

24www.evolutionpowertools.com450 Bevel Stop Adjustment• Loosen the Bevel Lock Handle and tilt the Cutting Head completely to the left until it rests

25www.evolutionpowertools.comENFRDENLITJP• Ensure that the Cutting Head is in the locked down position with the latching pin fully engaged in its soc

26www.evolutionpowertools.comUNLATCHING AND RAISING THE CUTTING HEAD (Fig. 21)WARNING: To avoid serious injury, NEVER perform the unlocking or lockin

27www.evolutionpowertools.comENFRDENLITJP• Slide the Cutting Head to the rear as far as it will go.• Tighten the slide lock screw. (Fig. 24)• Place

28www.evolutionpowertools.com• Always push the Cutting Head to the full rear position during each cut. (Fig. 28)• When the cut has been completed, r

29www.evolutionpowertools.comENFRDENLITJPBEVEL CUTTING  TILTING THE CUTTING HEADA bevel cut (Fig. 32) is made with the rotary table set at 00 mitre.

3www.evolutionpowertools.comENFRDENLITJP

30www.evolutionpowertools.comEnsure that the Crown Moulding is correctly positioned on the rotary table before making the cut.When cutting operations

31www.evolutionpowertools.comENFRDENLITJPINSTALLING or REMOVING a BLADEWARNING: Only carry out this operation with the machine disconnected from the m

32www.evolutionpowertools.comSILVER DUAL-SIDED INNER-FLANGE NORTH AMERICAN MODELS ONLYNorth American models only are supplied with a silver dual-sid

33www.evolutionpowertools.comENFRDENLITJP2) 16mm (5/8”) ARBOR BLADESWARNING: Only carry out this operation with the machine disconnected from the main

34www.evolutionpowertools.com8.12 USE OF OPTIONAL EVOLUTION ACCESSORIES Not supplied as original equipment. All accessories can be purchased from E

35www.evolutionpowertools.comENFRDENLITJP• Right Hand side. Loosen the support retaining screw located in the top front of the machines base.• Inser

FINAL SAFETY CHECKSCondition YesSlides Inserted through the Bevel Neck and connected to the Cutting Head. Locating lugs successfully deployedPositive

MAINTENANCENote: Any maintenance must be carried out with the machine switched off and disconnected from the mains/battery power supply.Check that all

38www.evolutionpowertools.comThe manufacturer of the product covered by this Declaration is: Evolution Power Tools, Venture One, Longacre Close, Holb

STEALTH25525539www.evolutionpowertools.comENFRDENLITJPProduct DetailsDescription: RAGE3-S/STEALTH 210mm TCT Multipurpose Sliding Mitre Saw Evolution

MACHINE SPECIFICATIONSMotor UK (230V ~ 50/60 Hz) Motor UK (110V ~ 50/60 Hz)Motor USA (120V ~ 60 Hz)No Load SpeedWeight CUTTING CAPACITIESMild Steel Pl

UKEvolution Power Tools LtdVenture OneLongacre CloseHolbrook Industrial EstateSheffieldS20 3FR+44 (0)114 251 1022USEvolution Power Tools LLC8363 Resea

METRIC IMPERIAL1500W 7A1500W 14A1500W 13A3000min-13000rpmN: 13kg / G: 17kg N: 23lb / G:38 lb6mm 1/4”3mm 1/8”300 x 60mm 11-3/4 x 2-3/8”210 x 35mm 8-1/4

1.3 IMPORTANTPlease read these operating and safety instructions carefully and completely. For your own safety, if you are uncertain about any aspe

(1.7) VIBRATION WARNING: When using this machine the operator can be exposed to high levels of vibration transmitted to the hand and arm. It is possib

INTENDED USE OF THIS POWER TOOLWARNING: This product is a Multipurpose Sliding Mitre Saw and has been designed to be used with special Evolution Multi

SAVE ALL WARNINGS & INSTRUCTIONS FOR FUTURE REFERENCEThe term “power tool” in the warnings refers to your mains-operated (corded) power tool or ba
