www.evolutionpowertools.com

BRUSH CHECKING AND/OR REPLACEMENT

• Disconnectthemachinefromthepower

supply.

• Placethemachineonalevel,securesurface.

• Unscrewandremovethetwo(2)brush

retaining caps from the motor housing.

• Withdrawthebrushes.

Note: If the carbon brush is less than ¼” long,

or if there are signs of burning or damage to

the carbon or the spring, replace the brushes.

• Fitthenewbrushes.

• Refitthebrushretainingcaps

• Runthemachinewithoutloadforseveral

minutes after brush replacement. This will

aid the ‘bedding in’ process.

Note: If, upon checking, the brushes are found

to be still serviceable, they can be returned to

their original position. It is important that they

are replaced in the same position as they were

removed from the machine.

ENVIRONMENTAL PROTECTION

Waste electrical products should not be

disposed of with household waste. Please

recycle where facilities exist. Check with your

local authority or retailer for recycling advice.
